Power top and side sealing six in one machine (patented product 201611000277. X)

This equipment is mainly used for heating and packaging of top, side, bottom and corner of soft packed power single / double pole ear battery, hipot test (short circuit test between positive electrode and aluminum film, short circuit test between negative electrode and aluminum film), ng sorting and automatic blanking.

technological process:

Clamp the battery on the insulating side of the machine → seal the battery on the bottom side of the machine by hand → seal the battery by hand, and then seal the battery by hand → press it into the bottom corner of the machine → seal the battery by hand.
